FL11S Series

LED flood lights are perfect for large open spaces that require lighting that provides great distribution and high lumen output. LED flood lights provide flexible lighting options where the lights can be mounted on poles, walls, roof tops or even on the ground. Beam angles and optics allow for narrow focused beams to large flood patterns to light up large areas of outdoor space.

PRODUCT INFORMATION & DOWNLOADS

Product Information

Features

►  Instant on/off

►  No humming or flickering
►  Unique design with anodized housing
►  Maintenance free operation
►  Cool beam - Does not produce Ultra Violet (UV) light or IR
  Environmentally friendly fully recyclable no mercury or other hazardous materials


Specifications

Watts Model# Lumen Replaces Dimensions Weight
12 W TG-FL11S-12W 1320 lm 40 W 151  x 80 x 35 mm 0.7 kg
18 W TG-FL11S-18W 1980 lm 50 W 151  x 115 x 35 mm 0.85 kg
24 W TG-FL11S-24W 2640 lm 80 W 151  x 135 x 35 mm 0.9 kg
36 W TG-FL11S-36W 3960 lm 100 W 151  x 205 x 35 mm 1.35 kg
48 W TG-FL11S-48W 5280lm 150 W 220  x 240 x 35 mm 2.0 kg
72 W TG-FL11S-72W 7920 lm 250 W 220  x 360 x 35 mm 2.85 kg


Lumen Efficacy 110 lm/W
Input Voltage 100-277 VAC
CCT 4000K / 5000K
CRI >70
Beam Angle 30°
Rated Life 30000 hours
Working Temperature -20°C to +45°C
Warranty 2 Years




Mounting Options

Yoke with 1/2‘‘ Threaded Fitting


Certificates

CE, RoHS


Applications

For mounting on poles or walls to illuminate building perimeters,
walkways, and landscapes or for wall graze and wall wash accent lighting
